ACE® Light Source
The ACE® is a cost effective and reliable 150 Watt cold light source which provides premium quality, intense light for Stereo Microscopy, Macroscopy and Machine Vision applications.
The modular concept of the Modulamp® assembly allows flexible adaptation depending on the users requirements.
The ACE® Light Source will fully illuminate active bundle diameters up to 16 mm (.63").

DCR®III Light Source
The DCR®III is a DC-regulated 150 watt-halogen light source which provides intense, cold illumination for Machine Vision applications.
Unique features:

• Electronic current limiting protects the unit from overheating due to defective and aging lamps.
• A lamp change indicator at the front panel of the unit alerts the user of impending lamp failure due to an open or partly shorted filament.
• Transient protection allows for remote location of te lamp, which enables the use of the DCR®III Remote Light Source Kit.
• The electronically stabilized internal switching power supply accepts universal input voltage from 90 - 265 VAC.

DCR®III Plus Light Source
The DCR® III Plus Light Source includes all the standard features of the DCR® III with added benefit of a built-in RS232 interface providing intense, cool illumination via remote control.

Unique features:

• Remote controllable using built-in RS232 interface.
• Designed to control up to three additional DCR®III units via a built-in 15-pin connector. (Expansion cable sold separately).
• Automatically restores user settings on power up.
• Enhanced communication available by embedding error checking codes in commands strings.
• Easier programmability with simplified command structure.

For even greater control, use the DCR® IV with fiber optic products that have an integrated reference bundle. This will maintain DDL lamp output and lamp to lamp variation within ±1%.

The MHR®-50 Light Source
The MHR®-50 Light Source is a compact and powerful Metal Halide cold light source for applications which require highly intense, white light such as Machine Vision and Microscopy.

The 50-watt Metal Halide lamp combines longevity (3500 h), excellent focusing efficiency and extremely high uniformity of the light spot

The MHR®-50 Light Source will fully illuminate active bundle diameters up to 12.7 mm (.5").
